As a premier manufacturer and trusted supplier of advanced wire processing equipment, we present the Premium Fakra Female End Riveting Press Machine. Engineered specifically for high-volume production facilities, this system seamlessly integrates precision mechanics with intelligent quality control to elevate your assembly capabilities.
Fully automated feeding, clamping, and riveting processes
Integrated high-resolution CCD visual inspection system
Heavy-duty, vibration-dampening cast steel framework
Optimized for maximum throughput and minimal material waste
| Quantity: | |
|---|---|
Step into the future of automotive and telecommunications assembly with the Premium Fakra Female End Riveting Press Machine. Designed to eliminate the bottlenecks of manual crimping, this sophisticated apparatus transforms raw components into flawless high-frequency connectors with rhythmic, uninterrupted precision. The moment you power on the machine, the quiet hum of its premium servo motors and the crisp, rhythmic actuation of its pneumatic cylinders convey a sense of absolute control and industrial reliability. Crafted with a robust cast steel structure, it stands resolute on the production floor, absorbing operational vibrations to maintain microscopic accuracy over millions of cycles. By automating the most intricate stages of wire processing—from precise clamping to final defect removal—this equipment empowers your assembly lines to achieve unprecedented output without sacrificing an ounce of quality. It is not merely a piece of machinery; it is a comprehensive manufacturing solution that drastically reduces labor dependency, minimizes costly material waste, and elevates your entire production standard to meet the most stringent automotive compliance requirements.
The following technical parameters detail the precise operational capabilities and structural specifications of the equipment, ensuring it meets the rigorous demands of your production environment.
Production capacity | 2.5S/PCS |
Utilization rate | >90% |
Defective rate | ≤1% (except for defects caused by incoming materials) |
Applicable products | according to relevant drawings |
Dimensions | L 2200mm*W 800mm*H 1950mm ((actual dimensions refer to the final 3D) |
Working voltage | AC220/50HZ |
Working air pressure | 5-6KG (water-free and oil-free) |
Working environment temperature | -10 degrees to 50 degrees |
Working environment humidity | 20 to 90% |
Safety device | leakage protection, emergency stop |
Achieving flawless connectivity in high-frequency applications requires equipment that leaves zero room for error. This riveting press machine is meticulously engineered to provide seamless operation, ensuring your facility consistently delivers top-tier components. The intuitive design reduces the learning curve for operators while maximizing daily throughput.
Intelligent Touch Interface: The advanced PLC and touch screen control system provide operators with crystal-clear diagnostics and effortless parameter adjustments, drastically reducing setup times between different production runs.
Flawless Defect Management: An automated sorting mechanism instantly isolates any anomalies detected by the visual system, ensuring that only perfect connectors proceed down the line, safeguarding your reputation for quality.
Pneumatic Precision: Utilizing a waterless and oilless air pressure system (4-6 kg/cm²), the machine delivers clean, consistent force, preventing the contamination of sensitive electronic components.
Continuous Material Flow: The heavy-duty automatic feeding system keeps the riveting station constantly supplied, eliminating manual loading pauses and driving up overall factory efficiency.
Vibration-Dampening Chassis: The heavyweight cast steel frame not only guarantees a long lifespan but also dampens micro-vibrations, which is critical for maintaining the tight tolerances required in FAKRA connector assembly.
Engineered for large-scale wire harness manufacturing, this system boasts an impressive equipment utilization rate exceeding 90%. By integrating highly accurate automated crimping processes, the finished product yield remains exceptionally stable at over 99.5%.
Drastically lowers scrap rates and minimizes expensive material waste.
Reduces comprehensive manufacturing costs across the assembly floor.
Ensures reliable, high-volume output to consistently meet tight delivery schedules.
The machine unifies a large-scale vibratory bowl for automatic feeding, exact positioning, and terminal crimping into one fluid sequence. Utilizing high-end servo systems alongside precision pneumatic components, it guarantees that the depth and force of every FAKRA female end crimp are perfectly identical.
Secures the absolute stability of automotive high-frequency signal transmission.
Eliminates human error and physical fatigue in the crimping process.
Delivers a smooth, rhythmic mechanical operation that operators can rely on shift after shift.
Equipped with a built-in, high-resolution CCD visual inspection system, the machine continuously monitors crimp quality and terminal alignment in real-time. The intelligent sorting mechanism automatically identifies and physically ejects defective pieces from the primary output chute.
Guarantees 100% qualified connector output for the downstream production line.
Strictly adheres to rigorous automotive-grade manufacturing standards (IATF16949).
Provides visual, data-backed assurance of every single operational cycle.
Constructed around a high-strength cast steel framework, the equipment operates with remarkable smoothness, emitting minimal noise while resisting external vibrations. The core electrical and pneumatic standard components are sourced from globally recognized, top-tier brands.
Maintains long-lasting, stable operation even in punishing, high-intensity industrial environments.
Significantly extends the maintenance lifecycle of the machinery.
Protects your capital investment through superior build quality and wear-resistant materials.
Deeply customized for automotive FAKRA high-frequency wire harness connectors, this press machine perfectly matches the high-standard assembly demands of various cutting-edge sectors. Its architecture supports modular customization, allowing your facility to adapt to future technological shifts.
Ideal for automotive electronics and electric vehicle (EV) manufacturing facilities.
Perfectly suited for smart connected communications and industrial control systems.
Offers scalable upgrades to keep pace with evolving harness designs and industry requirements.
The compact, wrap-around workstation design efficiently conserves valuable factory floor space. It features multiple access doors to facilitate rapid troubleshooting and routine maintenance without dismantling the core structure.
Standardized with electrical leakage protection and highly accessible emergency stop mechanisms.
Features an intelligent alarm system with clear auditory and visual prompts for immediate hazard recognition.
Maximizes operator safety while significantly lowering the technical threshold for daily operation.
