By combining smart detection technology with high-speed motion control, the machine significantly improves production efficiency, reduces human error and labor costs, and enhances overall product quality. It guarantees stable, low-loss data and power transmission, meeting the rigorous requirements of automotive wiring harness systems used in electric vehicles, intelligent driving, and automotive electronics.
This automated connector assembly and testing solution provides manufacturers with a cost-effective, high-precision, and scalable automation platform for next-generation automotive connectivity.
The Automobile High-speed Board-side Connector Assembly & Testing Equipment is designed with a sleek and modern industrial appearance, which can be customized to suit specific production environments and corporate aesthetics. Its protective enclosure features an intelligent access control system, ensuring safe operation, easy maintenance, and convenient monitoring during production. The overall design combines aesthetic appeal with ergonomic functionality, reflecting both professional craftsmanship and operator safety.
The mechanical structure of the equipment follows a standardized, modular, and systematic engineering approach, enabling flexible configuration, quick maintenance, and seamless upgrades for different connector assembly requirements. Each module has undergone extensive reliability and endurance testing, ensuring smooth operation, minimal vibration, and long-term stability even under high-speed production conditions.
All key components, electrical parts, and sensors are sourced from internationally recognized brands, ensuring high precision, durability, and consistency. The system adopts a servo motion control architecture, providing accurate positioning, fast response, and energy-efficient performance. With its low-noise operation and high-speed capabilities, the equipment delivers enhanced productivity, superior quality assurance, and optimized energy utilization, making it an ideal automation solution for automotive connector assembly and inspection.
Production capacity | ≤2.5S/PCS (utilization rate 95%) |
Yield | 99.5% (except for defective incoming materials) |
Applicable products | according to relevant drawings |
Dimensions | L7000mm/w1500mm/H1850mm |
Working voltage | AC220/50HZ |
Working air pressure | 5-6KG (water-free and oil-free) |
Working environment temperature | -10 degrees to 50 degrees |
Working environment humidity | 20 to 90% |
Safety device | leakage protection, emergency stop |
